Flex rigid pcb HDI Rigid Flex PCB| YMS PCB

Short Description:

China pcb manufacturer YMS has extensive experience, product knowledge and technical competency in Flex and Rigid-Flex manufacturing.

Parameters

Layers: 6L HDI Rigid Flex PCB

Board Thinkness:0.6mm+/-0.1mm

PCB thickness in flex section:0.08mm+/-0.03mm

Base Material:PI+FR4PP

Min mechanical Holes：0.15mm

Minimum Line Width/Clearance：0.075mm/0.075mm( 3mil/3mil)

Minimum Clearance between Inner Layer PTH and Line： 0.2mm

Size：199mm×176mm

Aspect Ratio：5.33 : 1

Surface treatment：ENIG

Speciality: rigid flex pcb, HDI ,Laser via copper plated shut

Differential impedance 100+7/-8Ω

Applications: Camera Moudule

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

What is a Rigid Flex PCB?

Rigid-Flex printed circuit boards are designed to provide solutions, and act as replacements for rigid PCBs. As the name suggests, these circuit boards are a hybrid of flex and rigid circuits. The advantage of this type is that they exhibit the benefits of both rigid as well as flexible circuit boards.

YMS Rigid Flex PCB manufacturing capabilities:

YMS Rigid Flex PCB manufacturing capabilities overview
Feature	capabilities
Layer Count	2-20L
Rigid-Flex Thickness	0.3mm-5.0mm
PCB thickness in flex section	0.08-0.8mm
copper Thickness	1/4OZ-10OZ
Minimum line Width and Space	0.05mm/0.05mm(2mil/2mil)
Stiffeners	Stainless steel，PI， FR4 ，Aluminum etc.
Material	Polyimide Flex+FR4,RA copper, HTE copper, polyimide, adhesive,Bondply
Min mechanical Drilled Size	0.15mm(6mil)
Min laser Holes Size:	0.075mm(3mil）
Surface Finish	Suitable Microwave/RF PCB urface finishes: Electroless Nickel, Immersion Gold, ENEPIG, Lead free HASL,Immersion Silver.etc.
Solder Mask	Green, Red, Yellow, Blue, White, Black, Purple, Matte Black, Matte green.etc.
Covrelay (Flex Part)	Yellow Coverlay, WhiteCoverlay,Black Coverlay
