Copper base PCBs also call Metal core PCB use copper as a primary base material in place of commonly used FR4. The copper base material is then covered with an insulating layer followed by a circuit layer. Copper core/based PCBs are known to have excellent heat dissipation and can be used for high frequency applications with minimal variation in performance over wide temperature ranges.

Parameters

  • Layers: 1
  • Thickness:3.0±0.15mm
  • Base Material:copper alloy
  • Min.Hole Size:0.5mm
  • Minimum Line Width/Space:0.5mm/0.5mm
  • Size:168mm×120mm
  • Thermal Conductivity:4.0 W/mk
  • Glass transition temperature: 170°C
  • Surface treatment:ENIG
  • Characteristics: High thermal conductivity, Countersink Hole
  • Applications: Automobile


Product Detail

Product Tags

Copper base Board Introduction

A special printed circuit board, which is made of printed circuit board on metal base copper clad plate, is called metal core printed circuit board, or metal core PCB (MCPCB) for short. Common metal core PCBs are aluminum base board, copper base board, iron base board and composite metal materials.
Copper base board, with its excellent heat dissipation performance, machining performance, electromagnetic shielding performance, dimension stability performance, magnetic properties and multi-function performance, has been more and more used in the hybrid integrated circuit auto motorcycle power equipment in the fields of high power electrical equipment and office automation. Especially, copper base board has been widely used as a base board in the LED packaging products.

Copper-Base-PCB

YMS copper based PCB manufacturing capabilities:

YMS copper based PCB manufacturing capabilities overview
Feature capabilities
Layer Count 1-4L
Thermal Conductivity(w/m.k) Aluminum PCB:0.8-10
Copper PCB:2.0-398
Board Thickness 0.4mm-5.0mm
copper Thickness 0.5-10OZ
Minimum line Width and Space 0.1mm/0.1mm(4mil/4mil)
Speciality Countersink,Counterbore drilling.etc.
Types of Aluminum Substrates 1000 series;5000 series;6000 series,3000 series.etc.
Min mechanical Drilled Size 0.2mm(8mil)
Surface Finish HASL, Lead free HASL,ENIG,Immersion Tin, OSP, Immersion Silver, Gold Finger, Electroplating Hard Gold, Selective OSP,ENEPIG.etc.
Solder Mask Green, Red, Yellow, Blue, White, Black, Purple, Matte Black, Matte green.etc.
